APC Smart-UPS On-Line, 5kVA, Rackmount 3U, 208V, 2x L6-20R+2x L6-30R NEMA outlets, Network Card+SmartSlot, Extended runtime, W/ rail kit [TAA]

Add to Wishlist
  • 5.4kVA/4.8kW double-conversion on-line pure sine wave 3U rackmount UPS
  • Ideal for servers, storage, voice/data networks, medical labs, and light industrial applications
  • Rack/Tower convertible (rail kit included)
  • Add up to 10 external battery packs (SRT192RMBPUS) for extended runtime

AED45,699.00

Add to Wishlist

This APC Smart-UPS is designed for IT professionals or network administrators to maintain business uptime and continuity. This 5kVA on-line 3U rackmount UPS provides pure sine wave power and extended runtime to support critical electronics during power disruptions. It comes with NEMA L6-30P input, 2x NEMA L6-30R and 2x L6-20R outlets. The UPS has an embedded Network Management Card for UPS network-based monitoring and management. The UPS comes with PowerChute Network Shutdown that provides graceful shutdown of physical servers, virtual machines, and HCI clusters. It has an additional SmartSlot for optional accessory card such as Dry Contact I/O card.

SKU: SRT5KRMXLTUS Category: Tag:

UPS Product Overview

Category Specification
Lead Time Usually in Stock
Product Type Uninterruptible Power Supply (UPS)
Range of Product Smart-UPS On-Line
Main Input Voltage 208 V
Other Input Voltage 240 V
Main Output Voltage 208 V
Other Output Voltage 240 V
kW Rating 4800 W
Rated Power (VA) 5400 VA
Input Connection Type NEMA L6-30P
Output Connection Type 2 NEMA L6-20R, 2 NEMA L6-30R
Number of Rack Units 3U
Cable Length 10 ft (3.05 m)
Number of Cables 1
Provided Equipment – Documentation CD
– Rack mounting hardware
– Rack mounting brackets
– Rack support rails
– User manual
– USB cable
– Warranty card
– Web/SNMP Management Card

Batteries & Runtime

Category Specification
Battery Type Lead-Acid battery
Extendable Run Time Yes (1)
Included Battery Modules 0
Battery Slots Empty 0
RBC Quantity 1
Typical Recharge Time 1.5 hours
Battery Life 3 to 5 years
Replacement Battery APCRBC140
Battery Charge Power 556 W rated
Efficiency View Efficiency Graph (link not provided)
Run Time View Runtime Graph (link not provided)

General Specifications

Category Specification
Power Module Filled Slots 0
Power Module Free Slots 0
Product Web Sub-family TAA Compliance
Redundant No
Topology Double Conversion Online

Physical Specifications

Category Specification
Color Black
Height 5.12 in (13 cm)
Width 17.01 in (43.2 cm)
Depth 28.31 in (71.9 cm)
Net Weight 123.00 lb (55.79 kg)
Mounting Location Front
Mounting Preference No preference
Mounting Mode Rack-mounted
Mounting Position Horizontal
Two Post Mountable No (0)
USB Compatible Yes

Input Specifications

Category Specification
Efficiency at Full Load 100…275 V adjustable (half load)
Input Frequency 40 – 70 Hz auto-sensing

Output Specifications

Category Specification
Bypass Type Internal Bypass (Automatic and Manual)
Crest Factor 3:1
Harmonic Distortion Less than 2%
Max Configurable Power (VA) 5000 VA
Max Configurable Power (Watts) 4800 W
Wave Type Sine wave
Output Frequency (sync to mains) 50/60 Hz ± 3 Hz sync to mains

Conformance & Certifications

Certifications
ENERGY STAR V2.0 (USA)
NOM
TAA Compliance

Environmental Conditions

Category Specification
Acoustic Level 55 dBA
Online Thermal Dissipation 1047 Btu/h
Operating Altitude 0–10000 ft
Operating Ambient Temperature 32–104 °F (0–40 °C)
Storage Ambient Temperature 5–113 °F (-15–45 °C)
Storage Altitude 0–50000 ft (0–15240 m)
IP Degree of Protection IP20
Operating Relative Humidity 0–95% non-condensing
Storage Relative Humidity 0–95% non-condensing
