APC Smart-UPS On-Line, 6kVA/6kW, Rackmount 4U, 230V, 6x C13+4x C19 IEC outlets, Network Card+SmartSlot, Extended runtime, W/ rail kit, Marine

Add to Wishlist

AED47,599.00

Add to Wishlist

UPS Product Specification Table

Category Specification
Overview High availability, ruggedized power protection for shipboard and other transportation applications
Lead Time Usually in Stock

Main Specifications

Feature Specification
Product or Component Type Uninterruptible Power Supply (UPS)
Run Time for Load 6000 W (Min-Max: 600–6000 W), 2 min 28 s
Max Capacity Used 100%
Main Input Voltage 230 V
Other Input Voltages 220 V, 240 V
Main Output Voltage 230 V
Other Output Voltages 220 V, 240 V
kW Rating 6000 W
Rated Power (VA) 6000 VA
Output Connection Types 6 × IEC 60320 C13, 2 × IEC Jumpers, 4 × IEC 60320 C19
Output Connector Type 1 × Hard Wire 3-wire (H, N + E)
Number of Rack Units 4U
Provided Equipment CD with software, Installation guide, Rack mounting hardware, Rack mounting brackets, Rack mounting support rails, Temperature probe, USB cable, Warranty card

Battery & Runtime

Feature Specification
Battery Type Lead-Acid battery
Extendable Runtime Yes (1)
Included Battery Modules 0
Typical Recharge Time 1 h
RBC Quantity 1
Battery Life 3–5 years
Replacement Battery APCRBC140
Battery Charge Power 893 W rated

General Information

Feature Specification
Number of Power Module Filled Slots 0
Number of Power Module Free Slots 0
Redundant No
Topology Double Conversion Online

Physical Characteristics

Feature Specification
Color Black
Height 6.85 in (17.4 cm)
Width 17.01 in (43.2 cm)
Depth 28.32 in (71.94 cm)
Weight 132.3 lb (60 kg)
Mounting Location Front
Mounting Preference No preference
Mounting Mode Rack-mounted
Two-Post Mountable No
USB Compatible Yes

Input Specifications

Feature Specification
Number of Input Connectors 1 × Hard Wire 3-wire (1PH+N+G)
Input Frequency 40–70 Hz (auto-sensing)

Output Specifications

Feature Specification
Bypass Type Internal Bypass (Automatic and Manual)
Crest Factor 3:1
Harmonic Distortion Less than 3%
Max Configurable Power (VA) 6000 VA
Max Configurable Power (W) 6000 W
Waveform Type Sine wave
Output Frequency 50/60 Hz ±3 Hz (sync to mains)

Conformance

Certifications CE, EAC, RCM, VDE
Marking CE Mark
Standards EN/IEC 62040-1:2019/A11:2021, EN/IEC 62040-2:2006/AC:2006, EN/IEC 62040-2:2018

Environmental Specifications

Feature Specification
Acoustic Level 55 dBA
Online Thermal Dissipation 1300 Btu/h
Operating Altitude 0–10,000 ft
Operating Temperature 32–104 °F (0–40 °C)
Storage Temperature 5–113 °F (-15–45 °C)
Storage Altitude 0–50,000 ft (0–15,240 m)
IP Degree of Protection IP20
Relative Humidity (Operating & Storage) 0–95% (non-condensing)
