UPS , Power Back up and accessories
APC Smart-UPS Ultra Tower Isolation/Step-Down Transformer, 5kVA, 8x 5-20R & 2x L6-20R & 1x L6-30R & 1x L14-30R NEMA outlets
- 3U height stepdown transformer
- Provides 120V output for 208V UPS
- (2) L6-30R (1)L5-13R (2)5-20R
AED9,499.00
The Smart-UPS Ultra SRTL 5kW, 3U rack/tower convertible, Step-Down Transformer lets you connect multiple voltage equipment to your existing SRTL5K power protection. User Selectable: 110V/ 120V/ 208V/ 240V, depending on the UPS output voltage and the Switch position. Connections: (2) L6-20R, (8) 5-20R, (1) L6-30R, (1) L14-30R Ships as tower Configuration. Install the step-down transformer to the left/above the compatible STLR 5kW UPS. Rackmount configuration is available with SRTRK2 rail kit accessory, sold separately.
š§¾ Overview
| Attribute | Details |
|---|---|
| Lead Time | Usually in Stock |
| Product Type | Transformer |
| Range of Product | Smart-UPS Ultra |
ā” Power Specifications
| Attribute | Details |
|---|---|
| Rated Power (VA) | 5000 VA (5 kVA) |
| Load Capacity | 5000 VA |
| Max Total Current Draw | 5000 A (per phase) |
š Input Specifications
| Attribute | Details |
|---|---|
| Main Input Voltage | 208 V |
| Input Connection | NEMA L6-30P |
| Input Frequency | 50/60 Hz |
| Cable Length | 3 ft (0.9 m) |
| Number of Cables | 1 |
š Output Specifications
| Attribute | Details |
|---|---|
| Main Output Voltage | 120 V |
| Other Output Voltage | 240 V |
| Number of Outlets | 12 total |
| Outlet Configuration | 8 x NEMA 5-20R |
š§° Included Equipment
| Items Included |
|---|
| User Manual |
š¦ Physical Specifications
| Attribute | Details |
|---|---|
| Color | Black |
| Height | 17.01 in (43.2 cm) |
| Width | 5.12 in (13 cm) |
| Depth | 25.98 in (66 cm) |
| Net Weight | 125.002 lb (56.7 kg) |
| Mounting Mode | Rack-mounted with kit |
| Mounting Preference | No preference |
š± Environmental Specifications
| Attribute | Details |
|---|---|
| Operating Temperature | 32ā104 Ā°F (0ā40 Ā°C) |
| Storage Temperature | 5ā113 Ā°F (-15ā45 Ā°C) |
| Operating Humidity | 0ā95% non-condensing |
| Storage Humidity | 0ā95% non-condensing |
| Operating Altitude | 0ā10,000 ft |
| Storage Altitude | 0ā50,000 ft (0ā15,240 m) |
ā Certifications & Standards
| Attribute | Details |
|---|---|
| Product Certifications | CSA |
| Standards | UL 1778 |
There are no reviews yet.
