04 3550600 052 7036860

APC Smart-UPS X, Line Interactive, 2000VA,Rack/tower convertible 2U, 100V-127V, 3x 5-15R+3x 5-20R+1x L5-20R NEMA,NMC,Extended runtime,10 Ft input cord

Add to Wishlist
  • 1920VA/1800W line interactive pure sine wave 2U rack/tower UPS (rail kit included)
  • User-selectable low voltage setting of 100V-127V
  • Add up to 10 external battery packs (SMX120RMBP2U)
  • Preinstalled NMC for network-based UPS monitoring & management
  • Graceful shutdown of physical servers, virtual machines and HCI clusters

AED14,299.00

Add to Wishlist

This APC Smart-UPS is designed for IT managers or network administrators to maintain business uptime, data transfer and continuity during prolonged power outages. The 2000VA line interactive 2U rack/tower UPS provides pure sine wave power to support critical electronics during power disruptions. The SMX comes with NEMA 5-20P input, 3x NEMA 5-15R, 3x NEMA 5-20R and 1x NEMA L5-20R outlets. The UPS has a preinstalled Network Management Card for UPS network-based monitoring and management. The Smart-UPS comes with PowerChute Network Shutdown that provides graceful shutdown of physical servers, virtual machines, and HCI clusters. This uninterrupted power supply can connect to EcoStruxure IT or third-party centralized management platforms.

SKU: SMX2KR2UNCX145 Category: Tag:
Category Attribute Value
Overview Lead Time Usually in Stock
Main Run Time for Load 10 min 56 s @ 1800 W
Min-Max Load 180–1800 W
Max Capacity Used 100%
Product or Component Type Uninterruptible Power Supply (UPS)
Batteries & Runtime Run Time View Runtime Graph
Efficiency View Efficiency Graph
Battery Type Lead-Acid battery
Extendable Run Time Yes (1)
Included Battery Modules 1
Battery Slots Empty 0
Typical Recharge Time 3 h
RBC Quantity 1
Battery Life 3–5 years
Replacement Battery APCRBC117
Battery Charge Power 229 W rated
General Provided Equipment CD with software, Documentation CD, Installation guide, Network Management Card, Rack mounting hardware, Rack Mounting brackets, Rack Mounting support rails, RS-232 cable, USB cable
Number of Power Modules 0
Power Module Filled Slots 0
Power Module Free Slots 0
Product Web Sub-family Network card pre-installed
Redundant No
Physical Rack Unit 2U
Cable Length 10 ft (3.05 m)
Number of Cables 1
Color Black
Height 3.35 in (8.5 cm)
Width 17.01 in (43.2 cm)
Depth 26.26 in (66.7 cm)
Product Weight 84.77 lb (38.45 kg)
Mounting Location Front
Mounting Preference Lower
Mounting Mode Rack-mounted
Two Post Mountable No
USB Compatible No
Input Main Input Voltage 120 V
Input Connection Type NEMA L5-20P
Efficiency at Full Load 75–154 V adjustable / 70–153 V
Input Frequency 50/60 Hz ± 3 Hz auto-sensing
Output Main Output Voltage 120 V
kW Rating 1800 W
Rated Power in VA 1920 VA
Output Connection Type 3 × NEMA 5-15R, 3 × NEMA 5-20R, 1 × NEMA L5-20R
Harmonic Distortion Less than 5%
Max Configurable Power (VA) 1920 VA
Max Configurable Power (Watts) 1800 W
Transfer Time 4 ms typical, 8 ms maximum
Topology Line Interactive
Waveform Type Sine wave
Output Frequency 50/60 Hz ± 3 Hz sync to mains
Conformance Product Certifications BSMI, CSA, NOM, TÜV, VCCI Class A
Equipment Protection Policy Lifetime: $150,000
Environmental Acoustic Level 55 dBA
Online Thermal Dissipation 203 Btu/h
Operating Altitude 0–10,000 ft
Operating Temperature 32–104 °F (0–40 °C)
Storage Temperature 5–113 °F (–15–45 °C)
Storage Altitude 0–50,000 ft (0–15,240 m)
Relative Humidity 0–95%
Storage Relative Humidity 0–95%
