APC Smart-UPS X, Line Interactive, 2200VA, Rack/tower convertible 2U, 208V-230V, 8x C13+1x C19 IEC, Network card, Extended runtime

Add to Wishlist
  • 2200VA/1980W line interactive pure sine wave 2U rack/tower UPS (rail kit included)
  • User-selectable high voltage setting of 200V-240V
  • Add up to 10 external battery packs (SMX120RMBP2U)
  • Preinstalled NMC for network-based UPS monitoring & management
  • Graceful shutdown of physical servers, virtual machines and HCI clusters

AED21,199.00

Add to Wishlist

This APC Smart-UPS is designed for IT managers or network administrators to maintain business uptime, data transfer and continuity during prolonged power outages. The 2200VA line interactive 2U rack/tower UPS provides pure sine wave power to support critical electronics during power disruptions. The SMX comes with IEC 320 C20 input (includes BS1363A, IEC 320 C20 and Schuko CEE 7/EU1-16P power cords), 8x IEC 320 C13 and 1x IEC 320 C19 outlets. The UPS has a preinstalled Network Management Card for UPS network-based monitoring and management. The Smart-UPS comes with PowerChute Network Shutdown that provides graceful shutdown of physical servers, virtual machines, and HCI clusters. This uninterrupted power supply can connect to EcoStruxure IT or third-party centralized management platforms.

SKU: SMX2200R2HVNC Category: Tag:

Overview

Feature Description
Presentation Intelligent and efficient network power protection from entry level to scalable runtime. Ideal for servers, POS systems, routers, switches, hubs, and other network devices.
Lead Time Usually in Stock

Main

| Product Type | Uninterruptible Power Supply (UPS) |

Batteries & Runtime

Battery Type Lead-Acid battery
Extendable Run Time Yes (1)
Included Battery Modules 0
Battery Slots Empty 0
Typical Recharge Time 3 hours
RBC Quantity 1
Battery Life 3–5 years
Replacement Battery APCRBC117
Battery Charge Power 233 W rated

General

Provided Equipment CD with software, Documentation CD, Installation guide, Network Management Card, Rack Mounting support rails, RS-232 cable, Temperature Probe, USB cable
Number of Power Modules 0
Filled Power Module Slots 0
Free Power Module Slots 0
Web Sub-Family Extended run
Redundant No

Physical

Rack Units 2U
Cable Length 6 ft (1.8 m)
Number of Cables 1
Color Black
Height 3.35 in (8.5 cm)
Width 17.01 in (43.2 cm)
Depth 26.26 in (66.7 cm)
Net Weight 82.10 lb (37.24 kg)
Mounting Location Front
Mounting Preference Lower
Mounting Mode Not rack-mountable
Two-Post Mountable No (0)
USB Compatible Yes

Input

Main Input Voltage 208 V / 230 V
Other Input Voltages 220 V / 240 V
Input Connection Types BS1363A British, IEC 320 C20, Schuko CEE 7 / EU1-16P
Efficiency Voltage Range 140–280 V
Input Frequency 50/60 Hz ± 3 Hz auto-sensing

Output

Main Output Voltages 208 V / 230 V
Other Output Voltages 220 V / 240 V
kW Rating 1980 W
Rated Power (VA) 2200 VA
Output Connection Types 8 × IEC 320 C13, 2 × IEC Jumpers, 1 × IEC 320 C19
Harmonic Distortion < 5%
Max Configurable Power (VA) 2200 VA
Max Configurable Power (Watts) 1980 W
Transfer Time 6 ms typical, 10 ms maximum
Topology Line Interactive
Wave Type Sine wave
Output Frequency (sync) 50/60 Hz ± 3 Hz sync to mains

Conformance

Certifications CE, EAC, IRAM, RCM, TISI, VDE, UK PSTI
Standards EN/IEC 62040-1:2019/A11:2021, EN/IEC 62040-2:2006/AC:2006, EN/IEC 62040-2:2018

Environmental

Acoustic Level 55 dBA
Thermal Dissipation 150 Btu/h
Operating Altitude 0–10,000 ft
Operating Temperature 32–104 °F (0–40 °C)
Storage Temperature 5–113 °F (-15–45 °C)
Storage Altitude 0–50,000 ft
Relative Humidity (Op/Storage) 0–95%
