BenQ LK936ST 5100-Lumen 4K UHD Short-Throw Laser DLP Projector

Add to Wishlist
Key Features
  • Brightness of 5100 Lumens
  • 4K UHD (3840 x 2160) Native Resolution
  • 1.1x Zoom & 0.81-0.89:1 Throw Ratio
  • 0.47″ 1-Chip DMD DLP & 92% of Rec.709
  • HDMI 2.0b, DisplayPort 1.2a, and HDBaseT
  • Laser Light with Up to 20,000 Hour Life
  • 360° Installation & Portrait Support
  • 3D Keystone Correction with Corner Fit
  • Image Shrink & Shift Without Distortion
  • Golf Mode for Lush Greens & Blue Skies

24,499.00 د.إ

Add to Wishlist

With exceptional color accuracy, brightness, and installation flexibility, the LK936ST 5100-Lumen 4K UHD Short-Throw Laser DLP Projector from BenQ can be the centerpiece of everything from your home theater, a retail or art installation, and even a virtual golf range. A 0.47″ single-DMD DLP system works with 5100 lumens of laser light to deliver stunning 4K resolution and 92% of Rec.709 for cinematic-grade color accuracy. Thanks to the short 0.81 to 0.89:1 throw, these detailed images can project up to 10′ tall from just 14-15′ away. A variety of adjustments let you project to almost any wall, ceiling, or floor, and HDBaseT network connectivity makes remote management fast and easy.

Installation & Adjustment Flexibility

The LK936ST is at home in almost any space, with 360° installation support and the ability to project in portrait orientation for vertical applications. Even if an off-center installation is required, up to 60% vertical and 23% horizontal lens shift can get your image where it needs to be.

After it’s installed, 3D keystone correction and Corner Fit lets you fix any trapezoidal images with ±40% vertical and horizontal correction and rotation either clockwise or counterclockwise. The image can even be shrunk to 75% of the original size in 0.5% increments without distortion, then shifted into place using the OSD menu. This kind of control and freedom allows for projection on not just walls and screens, but also angled walls, ceilings, and floors if needed.

Superior Imaging

Whether it’s art in a gallery, ads in a lobby, or movies and games at home, the LK936ST can make everything look clean and accurate thanks to the technologies used by the laser light source and DLP system.{C}



  • Brightness: Zero-deviation alignment of laser diodes improves the projector’s light efficacy.
  • Performance: Dual synchronized color wheels use an additive yellow segment, stimulating precise RGBY spectra for optimal chromatic performance and color saturation.
  • Durability: Over 2 million micromirrors reflect pure light through the color wheel, and a hermetically sealed DLP chip resists heat for over 20,000 hours of operation.





4K Image Upscaling Technology
To ensure the best image quality, LK936ST uses 4K Image Upscaling Technology to further enhance the quality of projected images. LK936ST automatically upgrades the resolution of all projected images to 4K, enhancing image details no matter the source resolution.
Golf Mode
BenQ worked with color experts and used examples from popular golf software to create Golf Mode, which is able to reproduce the lush greens and vivid blue skies of your favorite course. A quick setting option, Golf Mode corrects purple fringing using the blue and green colors from popular golf software and allows golfers to immerse themselves in pleasantly natural reproductions of blue sky and green grass.
Low Maintenance
Thanks to a hermetically sealed DLP chip, filter-free IP5X dust proofing, sealed laser modules, and enclosed light engines, dust is minimized to extend image quality and reduce maintenance costs over time.
DMS Local
DMS Local is management software for Windows OS that lets you remotely control multiple projectors over LAN or through the cloud using Agent Mode.
Additional Features
  • S/PDIF connection for 5.1-channel surround sound support
  • Compatible with many home automation control systems, letting you manage and control the projector with a PC or mobile device
  • HDBaseT supports audio and video signals, in addition to RS-232 and LAN control signals from a variety of sources from up to 328.1′ away
  • S/PDIF connection for 5.1-channel surround sound
  • Supports 24/7 continuous operation
  • Dual HDMI 2.0b and DisplayPort 1.2a inputs
  • Compatible with leading control systems, such as Extron, Crestron, AMX, and PJ-Link via LAN or RS-232 connections
SKU: LK936ST Category: Tag:
Display System
1-Chip 0.47″ DMD DLP
Native Resolution
3840 x 2160
Maximum Brightness
5100 Lumens (ANSI)
Throw Ratio
0.81 to 0.89:1
HDR Support
Yes, HDR10/Hybrid Log Gamma
Inputs/Outputs
2x HDMI 2.0b Audio, Video Input
1x DisplayPort 1.2 Audio, Video Input
1x RJ45 (Ethernet) Data Input/Output
1x RJ45 (HDBaseT) Audio, Control, Video Input/Output
1x 4-Pin DIN (VESA 3D Sync) Video Input
1x 4-Pin DIN (VESA 3D Sync) Video Output
1x DE-9/DB-9 (RS-232) Control Input
1x 1/8″ / 3.5 mm Mini Audio Input
1x 1/8″ / 3.5 mm Mini Audio Output
1x 12 V Trigger Control Input
1x USB-A Power Output
1x 1/8″ / 3.5 mm Mini Remote Input
1x 1/8″ / 3.5 mm Mini Remote Output
Light Source
Laser Phosphor
Image Display
Display System
1-Chip 0.47″ DMD DLP
Native Resolution
3840 x 2160
Supported Resolutions
Minimum: 640 x 480
Maximum: 3840 x 2160
Maximum Brightness
5100 Lumens (ANSI)
Offset
0%
Aspect Ratio
Native: 16:9
Dynamic Contrast Ratio
3,000,000:1
DLP Link 3D
Yes
Supported 3D Formats
Frame Sequential (up to 1080p)
Color Depth
10-Bit (1.07 Billion Colors)
Scan
Horizontal: 15 to 135 kHz
Vertical: 23 to 240 Hz
Latency
34 ms
Lens
Includes Lens
Yes
Aperture
f/1.83 to 1.86
Focal Length
8.6 to 9.4mm
Lens Shift
Vertical: ± 60%
Horizontal: ± 23%
Optical Zoom
1.1x
Throw Ratio
0.81 to 0.89:1
Features
Keystone Correction
Vertical: ± 40°
Horizontal: ± 40°
HDR Support
Yes, HDR10/Hybrid Log Gamma
Multi-Input Support (PIP/PBP)
Not Specified by Manufacturer
Ceiling Mountable
Yes
Rear Screen Projection
Yes
Built-In Speaker
Yes (Mono)
Speaker Power
10 W
Input/Output Connectors
Inputs/Outputs
2x HDMI 2.0b Audio, Video Input
1x DisplayPort 1.2 Audio, Video Input
1x RJ45 (Ethernet) Data Input/Output
1x RJ45 (HDBaseT) Audio, Control, Video Input/Output
1x 4-Pin DIN (VESA 3D Sync) Video Input
1x 4-Pin DIN (VESA 3D Sync) Video Output
1x DE-9/DB-9 (RS-232) Control Input
1x 1/8″ / 3.5 mm Mini Audio Input
1x 1/8″ / 3.5 mm Mini Audio Output
1x 12 V Trigger Control Input
1x USB-A Power Output
1x 1/8″ / 3.5 mm Mini Remote Input
1x 1/8″ / 3.5 mm Mini Remote Output
HDCP Support
Yes, Version 2.2
Hardware
Mobile App Compatible
No
Bluetooth
No
General
Light Source
Laser Phosphor
Expected Lamp Life
Medium Brightness: 20,000 Hours
Fan Noise
Medium Brightness: 40 dB
Low Brightness: 33 dB
Input Power
100 to 240 VAC, 50 / 60 Hz
Power Consumption
Medium Brightness: 440 W
Standby Mode (Lamp Off): < 0.5 W
Operating Temperature
32 to 104°F / 0 to 40°C
Dimensions (W x H x D)
16.4 x 6.5 x 13.8″ / 416.0 x 166.0 x 351.0 mm
Weight
15.4 lb / 7 kg
Packaging Info
Package Weight
20.725 lb
Box Dimensions (LxWxH)
20.6 x 18.4 x 11.4″
