BZBGEAR 4×2 8K60 HDMI 2.1 Matrix Switcher with Audio De-Embedder


  • 4 HDMI Inputs, 2 HDMI Outputs
  • Supports HDMI 2.1 & HDCP 2.3
  • Up to 8K60 Resolution
  • Audio De-Embedding to Optical/Analog Out
  • 4:4:4 Chroma Subsampling and HDR Support
  • 40 Gb/s Video Bandwidth
  • Automatic Downscaling
  • HDR Support
  • Built-In EDID DIP Switch

AED3,499.00

Share up to four HDMI devices with up to two displays and de-embed audio to analog and digital outputs using thisĀ 4×2 8K60 HDMI 2.1 Matrix Switcher with Audio De-EmbedderĀ fromĀ BZBGear. The sleek user-friendly device is easy enough to operate for recreational usage, but it also offers the advanced features one requires for professional applications. Boasting four HDMI inputs and two HDMI outputs, the switcher handles resolutions up to 8K60 and has 4:4:4 chroma subsampling and full support for various flavors of HDR.

A video bandwidth of 40 Gb/s ensures reliable delivery of exceptional picture and audio quality, making it an ideal solution for routing multiple home entertainment devices, but it is also great for gaming thanks to its support for 4K resolution at up to 120 Hz, which provides reliable imaging with reduced motion blur during fast-paced games. Automatic downscaling can take your video from 8K to 4K or even down to 2K, and a built-in EDID DIP switch allows you to quickly set your EDID management to ensure wide compatibility with a multitude of devices. The compact design facilitates easy installation and an included IR remote provides you with control for those times when the unit may be placed slightly out of reach.

Key Features
  • HDMI 2.1 and HDCP 2.3 compliant
  • 40 Gb/s video bandwidth
  • Supports video resolution up to 8K60 4:2:0 10-bit, 8K30 4:4:4 10-bit, and 4K120 4:4:4 10-bit
  • VRR, FVA, ALLM supported
  • Supports HDR, HDR10, HDR10+, Dolby Vision, HLG passthrough
  • Supports HDMI audio formats: Dolby Digital/Plus/EX, Dolby True HD, Dolby Atmos, DTS, DTS-EX, DTS-96/24, DTS High Res, DTS-HD Master Audio, DSD
  • Input 1 and Output 1 ports support ARC\eARC
  • Audio de-embedding via analog and digital out ports
  • Built-in equalizer, retiming, and driver
  • Advanced EDID management
  • Auto switching is supported
  • Compact design for easy and flexible installation
SKU: BG-8K-42MA Category: Tag:
Processing
Switching Type
IR Remote, Pushbutton
Processing Resolution
8K at 60
Color Processing
10-Bit 4:4:4 RGB
10-Bit 4:4:4 YCbCr
10-Bit 4:2:2 YCbCr
8-Bit 4:2:0 YCbCr
12-Bit
Input
Video Inputs
4x HDMI (2.1) Female
Input Video Format
HDMI (8/10/12-Bit 4:4:4/4:2:2/4:2:0)
8K at 30/60 fps
UHD 4K at 24/60 fps
1080p
Input Audio Format
LPCM (Linear Pulse-Code Modulation)
Embedded Audio Input
HDMI
Output
Video Outputs
2x HDMI Female
Output Video Format
HDMI (8/10/12-Bit 4:4:4/4:2:2/4:2:0 RGB, YCC)
8K at 30/60 fps
UHD 4K at 24/60 fps
1080p
Audio Outputs
1x TOSLINK 8-Channel S/PDIF Female
1x 1/8″ / 3.5 mm TRS Stereo Analog Female
Output Audio Format
S/PDIF
Analog
Embedded Audio Output
HDMI
Connectivity
Other I/O
1x Micro-USB Firmware Input
HDCP Support
Yes, Version 2.3
HDR Support
Yes, HDR10/HDR10+/Dolby Vision/Hybrid Log Gamma
DTS Compatibility
DTS, DTS 96/24, DTS-HD Express, DTS-HD High Resolution, DTS-HD Master Audio
Dolby Compatibility
Dolby Atmos, Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby TrueHD
Hardware
Wi-Fi
No
Bluetooth
No
Power
Power I/O
1x Barrel (5 VDC at 2 A) Input
Power Consumption
Device: 2.05 W
Environmental
Operating Temperature
32 to 104°F / 0 to 40°C
Storage Temperature
-4 to 140°F / -20 to 60°C
Operating Humidity
20 to 90%
General
Dimensions
7.9 x 3.3 x 0.8″ / 200 x 85 x 21Ā mm
Weight
0.9Ā lb / 411Ā g
Packaging Info
Package Weight
1.675 lb
Box Dimensions (LxWxH)
10.3 x 6.6 x 3.1″
