Cisco ME 3400G-12CS AC Ethernet Access Switch – switch – 12 ports – managed ME-3400G-12CS-A-RF

Availability:

10 in stock
Add to Wishlist

12,099.00 د.إ

10 in stock

Add to Wishlist

Cisco Metro Ethernet Access Layer 3 Switch ME-3400G-12CS-A-RF 3400G-12CS



Overview

The Cisco ME 3400G-12CS AC Switch is positioned for service providers who want to offer higher-bandwidth services. Equipped with dual-purpose interfaces and redundant power supplies, this Gigabit switch can also be positioned for in-building aggregation.

  • 12 dual-purpose (10/100/1000 and Small Form-Factor Pluggable) ports
  • 4 SFP-based Gigabit Ethernet and 100BASE-X ports
  • Dual fixed redundant AC power supplies
  • 26-mpps forwarding rate
  • 1 rack unit (RU) multilayer switch
  • Purpose-built Gigabit Ethernet access switch for the Metro Ethernet market
SKU: ME-3400G-12CS-A-RF Category: Tags: ,

Specifications

General
Device Type Switch – 12 ports – L3 – managed
Enclosure Type Desktop 1U
Subtype Gigabit Ethernet
Ports 12 x 10/100/1000 + 12 x shared SFP + 4 x SFP
MAC Address Table Size 8K entries
Routing Protocol OSPF, BGP-4, IS-IS, RIP-1, RIP-2, EIGRP, PIM-SM, static IP routing, PIM-DM
Remote Management Protocol SNMP 1, SNMP 2, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3
Authentication Method Secure Shell (SSH), RADIUS, TACACS+
Features Layer 3 switching, layer 2 switching, trunking, VLAN support
Compliant Standards IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s
RAM 128 MB
Flash Memory 32 MB flash
Status Indicators Port status, link OK, status, link/activity
Expansion / Connectivity
Interfaces 12 x 1000Base-T RJ-45 1 x console RJ-45 management 16 x SFP (mini-GBIC)
Power
Power Device Internal power supply
Installed Qty 2 (installed) / 2 (max)
Power Redundancy Yes
Voltage Required AC 120/230 V (50/60 Hz)
Power Consumption Operational 80 Watt
Miscellaneous
Compliant Standards NEBS level 3, FCC Class A certified, TUV GS, CISPR 22 Class A, EN 60950, NOM, VCCI-I, IEC 60950, EN55024, EN55022 Class A, UL 60950 Third Edition, AS/NZ 3548 Class A, FCC Part 15, MIC, CSA C22.2 No. 60950 Third Edition, EN 300 386
Pricing Type Refurbished
Dimensions & Weight
Width 17.5 in
Depth 11 in
Height 1.7 in
Weight 9.26 lbs
Environmental Parameters
Min Operating Temperature 32 °F
Max Operating Temperature 122 °F
Humidity Range Operating 5 – 95%
General
Authentication Method Secure Shell (SSH), RADIUS, TACACS+
Compliant Standards IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s
Device Type Switch – 12 ports – L3 – managed
Enclosure Type Desktop 1U
Features Layer 3 switching, layer 2 switching, trunking, VLAN support
Flash Memory 32 MB flash
MAC Address Table Size 8K entries
Ports 12 x 10/100/1000 + 12 x shared SFP + 4 x SFP
RAM 128 MB
Remote Management Protocol SNMP 1, SNMP 2, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3
Routing Protocol OSPF, BGP-4, IS-IS, RIP-1, RIP-2, EIGRP, PIM-SM, static IP routing, PIM-DM
Status Indicators Port status, link OK, status, link/activity
Subtype Gigabit Ethernet
Dimensions & Weight
Depth 11 in
Height 1.7 in
Weight 9.26 lbs
Width 17.5 in
Environmental Parameters
Humidity Range Operating 5 – 95%
Max Operating Temperature 122 °F
Min Operating Temperature 32 °F
Expansion / Connectivity
Interfaces 12 x 1000Base-T RJ-45 ¦ 1 x console RJ-45 management ¦ 16 x SFP (mini-GBIC)
Miscellaneous
Compliant Standards NEBS level 3, FCC Class A certified, TUV GS, CISPR 22 Class A, EN 60950, NOM, VCCI-I, IEC 60950, EN55024, EN55022 Class A, UL 60950 Third Edition, AS/NZ 3548 Class A, FCC Part 15, MIC, CSA C22.2 No. 60950 Third Edition, EN 300 386
Pricing Type Refurbished
Power
Installed Qty 2 (installed) / 2 (max)
Power Consumption Operational 80 Watt
Power Device Internal power supply
Power Redundancy Yes
Voltage Required AC 120/230 V (50/60 Hz)
