MuxLab 5×1 USB-C/HDMI Presentation Switcher with Dante

Add to Wishlist
  • USB-C & HDMI Input, HDMI/HDBaseT Output
  • HDBaseT Transmitter/Receiver Setup
  • Supports Resolutions up to UHD 4K30
  • Analog/Dante Audio Embed/De-Embed
  • Auto, IP, Front-Panel & Remote Control
  • EDID Management, HDCP 2.2 Compliant

AED8,099.00

Add to Wishlist

TheĀ 5×1 USB-C/HDMI Presentation Switcher with DanteĀ fromĀ MuxlabĀ allows you to connect cable boxes, laptops, Blu-ray players, game consoles, and other HDMI or USB presentation sources to your 4K TV, HDTV, or projector. It also supports Dante audio embedding and de-embedding via IP, to expand your audio capabilities, as well as analog audio input/output. The switcher includes the main transmitter switch and an HDBaseT receiver to transmit video over longer distances.

The switcher supports auto-switching of its three HDMI and two USB-C inputs, and it allows you to toggle your sources rapidly using the switch button, RS-232, via CEC using the integrated USB-A KVM, or via IR remote control. It is HDCP compliant for compatibility with HDCP protected devices, like most cable boxes, and it features advanced EDID support for compatibility with most displays. The switcher is powered via the included power adapter, and the receiver is powered via the transmitter using PoE, so only one adapter is required.

Features
  • 18 Gb/s video bandwidth 5×1 switcher
  • HDMI 2.0b, HDCP 2.2, and DP 1.2 complaint
  • Support video resolution up to 4K60 4:4:4
  • Support HDBaseT 3.0 with PoE
  • Support 5×1 seamless switching
  • Up to five categories of multiview display modes: Single/PIP/PBP/Triple/Quad
  • Dante 2×2 audio embedding input and output
  • Local USB-A 2.0 KVM switching and extending USB 2.0 over HDBaseT 3.0
  • Supports analog/Dante audio embedding, analog/Dante audio de-embedding output
  • Manual switching or automatic switching
  • CEC/RS-232 control external devices
  • Flexible control via front-panel buttons, IR remote, RS-232, TCP/IP, or Web GUI
  • Advanced EDID management
  • Supports standard PoE power supply from transmitter to receiver (TX_PSE, RX_PD)
SKU: 500533 Category: Tag:
Processing
Switching Type
IR Remote, Pushbutton, Software
Input
Video Inputs
3x HDMI (2.0b) Female
2x USB-C (UVC) Female
Input Video Format
HDMI / USB-C (8/10/12-Bit 4:2:2/4:2:0 RGB, YCC)
DCI 4K up to 50/60 fps
UHD 4K up to 24/30/50/60 fps
1080p up to 50/60 fps
HDMI / USB-C (8-Bit 4:4:4 RGB, YCC)
DCI 4K up to 50/60 fps
UHD 4K up to 25/30/50/60 fps
1080p up to 50/60 fps
1920 x 1200 at 60 fps
1360 x 768 at 60 fps
WXGA (1280 x 800) at 60 fps
720p at 50/60 fps
XGA (1024 x 768) at 60 fps
Audio Inputs
1x Block 5-Pin Stereo Analog Female
1x RJ45 Female
Input Audio Format
Analog: 48 kHz
Dante: 48 kHz / 24-Bit
Embedded Audio Input
1/8″ / 3.5mm
RJ45
Output
Video Outputs
1x HDMI (2.0b) Female
1x RJ45 (HDBaseT) Female
Output Video Format
HDMI / RJ45 (8-Bit)
UHD 4K 50/60 fps
Audio Outputs
1x Block 5-Pin Stereo Analog Female
Output Audio Format
Analog: 48 kHz
LPCM (Linear Pulse-Code Modulation): 48 kHz / 24-Bit
Embedded Audio Output
HDMI
RJ45
Connectivity
Other I/O
2x USB-A Control, 2.0
1x USB-B Control, 2.0
1x Block 3-Pin Control, RS-232
HDCP Support
Yes, Version 2.2
Wi-Fi
No
Bluetooth
No
Power
Power I/O
1x Proprietary (24 VDC at 8 A) Input
Power Consumption
Power Supply: 100 to 240 VAC (150 W)
Environmental
Operating Temperature
32 to 104Ā°F / 0 to 40Ā°C
Storage Temperature
-4 to 140Ā°F / -20 to 60Ā°C
Operating Humidity
20 to 90%
Storage Humidity
20 to 90% (Non-Condensing)
General
Certifications
FCC, CE, RoHS
Dimensions
8.7 x 5.9 x 1.7″ / 220 x 150 x 44Ā mm
Weight
2.67Ā lb / 1.21Ā kg
Packaging Info
Package Weight
7.85 lb
Box Dimensions (LxWxH)
16.8 x 8.3 x 4.7″
