QOMO QView QD3900 HDMI Document Camera with Built-In Annotation Software (NTSC/PAL)


د.إ9,999.00

QOMO QD3900Ā Overview

The NTSC/PAL compatibleĀ QOMO HiteVision QView QD3900 HDMI Document CameraĀ features a 2MP CMOS sensor and can output video up to 1080p resolution. Featuring a variety of video inputs and outputs, including VGA, composite video, and HDMI, this document camera can serve as a retrofit for your classroom, lab, or business. It can replace your existing document camera, allowing for a transition from analog to digital.

HDMI video input allows you to connect a laptop, DVD player, or other HDMI devices. In addition, you can even use the QD3900 Document Camera as a pass-through switcher, eliminating the need for additional equipment.Ā The camera has a knob on the head for zooming. With a built-in annotation software, you can annotate on a touch panel straight from the camera.

The document camera features 12x optical and 22x digital zoom, which translates into a total zoom of 264x. The zoom, combined with HD 1080p resolution and RS-232 connectors for control, makes the camera an appropriate choice even for integrators.

The device serves as a media center with its A4-size backlit stage that can fit a textbook or paper document, an internal memory that can store up to 128 images, and the bundled image/video capture software for Windows and Mac OS.

Features

VGA, composite video, and HDMI inputs and outputs
RS-232 connectivity for document camera and projector
HD 1080p resolution
12x optical zoom and 22x digital zoom
A4 size backlit stage
Internal memory stores up to 128 images
Included image/video capture software
Compatible with GradeCam software (sold separately)
Kensington lock
USB Type-A port to connect a mouse

Applications

Industries: Education, corporate, video conferencing, legal, scientific research, medical, military
Zoom in to examine bone and tissue cell structures, and compare side-by-side the textbook image with the actual cells
Display documents during a meeting for quick and easy sharing; digitally annotate over the document and save it to your computer
Video conference with other classes or business partners
Use the built-in camera switcher/scaler to display computers, DVDs, and other media sources

QOMO QD3900Ā Specs

Camera
Image Sensor 2 MP CMOS
Output Resolutions XGA, SXGA, WXGA, 720p, 1080p
Optical Zoom 12x
Digital Zoom 22x
Focus Auto / manual selectable
White Balance Auto
Rotation Vertically 330Ā°
Connectors
Video Inputs 1 x HDMI, 2 x VGA, 1 x composite video
Video Outputs 1 x HDMI, 2 x VGA, 1 x composite video
Audio Inputs 3 x 3.5 mm audio, 1 x 1/4″ for mic
Audio Output 1 x 3.5 mm
USB 1 x USB Type-A mouse control
RS-232 Connector For PC: 1 x 9-pin D-Sub
For Projector: 1 x 6-pin PS/2
Imaging
Image Storage 128 images, 4 x 4 multiple screen display
Functions Negative, Black & White / Color, Freeze, Split, Title, Mirror, Text, Enhancement
Rotation 0, 90, 180, 270Ā°
Shooting Area 12.5 x 9.5″ (317.5 x 241.3 mm)
PC Requirements
Minimum Hardware Requirements CPU: 2.4 GHz
Memory: 256 MB
USB Port USB 2.0
Operating System Windows XP / Vista / 7 / 8, Mac, Linux
Lights
Arm 2 x 1.5 W LED
Backlight 2.5 W LED
Other
Light Box 8.5 x 11″ (215.9 x 279.4 mm)
Power Supply Input: 100 to 240 VAC, 50/60 Hz, 1.5 A
Output: 12 V, 4 A
Power Consumption 20 W
Dimensions (WxDxH) When Setup: 20.0 x 21.0 x 22.5″ (508.0 x 533.4 x 571.5 mm)
When Folded: 20.0 x 16.0 x 4.5″ (508.0 x 406.4 x 114.3 mm)
Weight 12.00 lb (5.44 kg)
Packaging Info
Package Weight 15.5 lb
Box Dimensions (LxWxH) 24.25 x 19.5 x 8″
