Technical specifications
| LCD feature | Specification | |||
|---|---|---|---|---|
| Display size | 22-inch (55.8 cm) diagonal and viewable image | |||
| Display type | Thin-Film Transistor LCD active matrix
BriteView technology |
|||
| Input terminal | HDMI connector (version 1.3)
DVI-D single-link connector VGA connector |
|||
| Other connectors | USB ports:
3.5 mm Stereo mini jack input (for microphone) |
|||
| Integrated speakers | 2 watts per speaker | |||
| Scanning frequency | Horizontal scan range 24-82 KHz
Vertical scan range 48-76 Hz |
|||
| Viewing angle | Horizontal viewing angle: 160 degrees
Vertical viewing angle: 160 degrees |
|||
| Recommended resolution (H x V) | 1680 x 1050 @ 60 Hz | |||
| Contrast ratio | Up to 1000:1 | |||
| Dynamic Contrast ratio | Up to 3000:1
|
|||
| Response time | 3 ms (G-to-G typical) | |||
| Pixel pitch | 0.282 mm | |||
| HDCP (High-bandwidth Digital Content Protection) | Support for HDCP enables the monitor to display HDTV resolution if connected by the DVI connector. A monitor without HDCP support, or connected by analog VGA, causes the displayed video to be downgraded in quality to a DVD-like resolution that is less than HDTV.
HDCP is also a content protection system. The goal of HDCP is to prevent transmission of non-encrypted high definition content. |
|||
| Power source – AC/DC adapter | Input rating: 100 to 240V~
frequency: 50~60Hz Power consumption: 65 watts maximum power consumption in operating mode, <2 W in sleep mode |
|||
| Operating environment | Temperature: 41 degrees F to 95 degrees F (5 degrees C to 35 degrees C )
Humidity: 20% RH through 80% RH (non-condensing) |
|||
| Storage environment | Temperature: -29 degrees F to 140 degrees F (-20 degrees C to 60 degrees C)
Humidity: 5% RH through 95% RH (non-condensing) |
|||
| Dimensions | H x W x D (unpacked):
18.9 x 20.5 x 11.3 inches (48.1 x 52.3 x 28.9 cm) |
|||
| Weight | Unpacked: 19.8 lbs (9 Kg) | |||
| EMI standard | FCC Class B | |||
| Mounting | Standard VESA 4-hole 100 mm x 100 mm | |||
| EPA Energy Star | As an Energy Star Partner, Hewlett-Packard has determined that this product meets the Energy Star guidelines for energy efficiency. |
