WS-C3560X-24P-L Catalyst 3560-X Switch

Cisco Catalyst WS-C3560X-24P-L is 24 Gigabit Ethernet POE+ ports standalone switch in LAN base feature set with no stacking option. Four optional network modules and license-base software feature provide flexibility, scalability and feature extensibility in order to reduce the cost of development of business needs. WS-C3560X-24P-L support IEEE802.3at standard to allocate up to 30W power on each port in total 435W POE budget to power up IP phones, wireless and video; customers can specify the power setting on individual port in command line setting. LAN base feature set offers up to 255-Vlans and comprehensive layer 2 feature with static routing and SVI interface supporting.

WS-C3560X-24P-L is designed for enterprise access layer switching; however, customers can transparently upgrade the software feature to by purchasing either IP base license or IP services license to activate layer 3 capability, 1005 VLans supporting. WS-C3560X-24P-L comes with one default power supply module, customers can purchase additional power supply insert into power supply bay 2 in order to power redundancy.

WS-C3560X-24P-L

Cisco Catalyst 3560-X Series Switch

24 * 10/100/1000 Gigabit Ethernet POE+ ports with optional uplink network modules435W POE power budget with up to 30W per portDual redundant, modular power supplies and fansLAN base feature set with upgrade option to IP base or IP serviceLayer 2 switching with static routing and SVI supporting64MB flash and 256 memory (DRAM)USB Type-A and Type-B ports for storage and console respectively and an out-of-band Ethernet management port

                                                                                                     Figure 1

Cisco Catalyst 3560-X Series Switches support 4 optional network modules for uplink ports (Figure 1);
The default switch configuration doesn’t include the uplink module;
When purchasing switch, customers have flexibility to choose any group of network modules described below:

                                                                                              Figure 2

Dual Redundant Modular Power Supplies

Cisco Catalyst 3750-X Series and 3560-X Series Switches support dual redundant power supplies (Figure 2);
One power supply is shipped with the switch by default;
Other power supply/suppliers can be purchased when ordering the switch or next time according to your needs.
If only one power supply is installed, it should always be in the power supply bay 1.

Table below shows the different power supplies available in these switches and available PoE power.

Power Supply Models
