04 3550600 052 7036860

APC Smart-UPS, Line Interactive, 2200VA, Lithium-ion, Rackmount 2U, 120V, 1x NEMA L5-20R+6x NEMA 5-20R outlets, SmartConnect Port+Network Card, AVR

Add to Wishlist
  • 1920VA/1920W line interactive pure sine wave 2U rackmount UPS
  • Ideal for small edge environment, back office, network infrastructure and IDF/MDF closets
  • Lithium-ion battery minimizes the need to replace battery during the life time of UPS
  • Cloud-based remote power monitoring via SmartConnect Ethernet Port

AED26,199.00

Add to Wishlist

This APC Smart-UPS is designed for IT professionals or network administrators to maintain business uptime and continuity. The 1920VA line interactive 2U rackmount UPS provides pure sine wave power to support critical electronics during power disruptions. It comes with NEMA L5-20P input, 6 NEMA 5-20R and 1 NEMA L5-20R outlets. It has a preinstalled Network Management Card for UPS network-based monitoring and management. It has a preinstalled Network Management Card for UPS network-based monitoring and management. It comes with PowerChute Network Shutdown that provides graceful shutdown of physical servers, virtual machines, and HCI clusters. It offers cloud-based remote power monitoring, UPS firmware upgrades, remote diagnostics and proactive email notifications with recommended actions. The SMTL UPS has a 5-year warranty on the UPS and Lithium-ion battery. The UPS can connect to EcoStruxure IT or third-party centralized management platforms. It provides surge protection against lightning strikes, power sags, brownouts and surges.

SKU: SMTL2K2RM2UCLNC Category: Tag:
Category Attribute Value
Overview Lead Time Usually Ships within 2 Weeks
Main Run Time for Load 7 min 42 s @ 1920 W
Min-Max Load 192–1920 W
Max Capacity Used 100%
Product or Component Type Uninterruptible Power Supply (UPS)
Complementary Communication Port Type SmartConnect Ethernet port
Software Package SmartConnect software for remote monitoring
Batteries & Runtime Run Time View Runtime Graph
Efficiency View Efficiency Graph
Battery Type Li-Ion (Lithium Ion)
Battery Notes Based on measured runtime; actual results vary
Extendable Run Time 0
Typical Recharge Time 2 h
RBC Quantity 1
Battery Design Life 8–10 years
Battery Charge Power 216 W rated
Replacement Battery APCRBC174-LI
General Provided Equipment Rack brackets, support rails, screws, washers, USB cable, Ethernet cable
Number of Power Modules 0
Product Web Sub-family Cloud-enabled monitoring
Redundant No
Physical Rack Unit 2U
Cable Length 8 ft (2.4 m)
Color Black with silver front bezel
Height 3.39 in (8.6 cm)
Width 17.01 in (43.2 cm)
Depth 26.89 in (68.3 cm)
Product Weight 70.3 lb (31.9 kg)
Mounting Preference Lower
Mounting Mode Rack-mounted
USB Compatible Yes
Input Main Input Voltage 120 V, 125 V, 110 V
Other Input Voltage 110 V, 125 V
Input Connection Type NEMA L5-20P
Input Protection Type Circuit breaker
Efficiency Range 82–144 V
Number of Input Connectors 1
Input Frequency 50/60 Hz ± 3 Hz auto-sensing
Output Main Output Voltage 120 V, 125 V, 110 V
Other Output Voltage 110 V, 125 V
kW Rating 1920 W
Rated Power in VA 1920 VA
Output Connection Type 1 × NEMA L5-20R, 6 × NEMA 5-20R
Crest Factor 3:1
Harmonic Distortion Less than 5%
Max Configurable Power (VA) 2200 VA
Max Configurable Power (Watts) 1980 W
Transfer Time 6 ms typical, 10 ms maximum
Topology Line Interactive
Waveform Type Sine wave
Output Frequency 50/60 Hz ± 3 Hz sync to mains
Conformance Product Certifications cULus, ENERGY STAR V2.0 (USA)
Equipment Protection Policy Lifetime: $150,000
Environmental Acoustic Level 55 dB
Online Thermal Dissipation 215 Btu/h
Operating Altitude 0–10,000 ft
Operating Temperature 32–104 °F (0–40 °C)
Storage Temperature 5–113 °F (–15–45 °C)
Storage Altitude 0–25,000 ft (0–7,620 m)
IP Degree of Protection IP20
Relative Humidity 0–95% non-condensing
Storage Relative Humidity 0–95% non-condensing
