APC Smart-UPS RT 3000VA 230V – Marine

Add to Wishlist
  • Ideal for providing uninterrupted power in critical marine applications
  • DNV type approved
  • Hot-swappable, front-accessible, user replaceable batteries
  • SNMP and Ethernet connectivity are optional
  • Operating temperature up to 55°C

AED24,699.00

Add to Wishlist

The APC Smart-UPS RT is an online UPS with a power rating of 3000VA and output power capacity of 2100 watts. It includes multiple output connections such as IEC 60230 and IEC Jumpers. This model is includes a lead-acid battery and is suitable for marine applications. The UPS features double conversion online technology and sine wave output.

SKU: SURTD3000XLIM Category: Tag:

UPS Product Specification Table

Category Specification
Overview High density, double-conversion on-line power protection with scalable runtime
Lead Time Usually in Stock

Main Specifications

Feature Specification
Run Time for Load 2100 W (Min-Max: 210–2100 W), 12 min 55 s
Max Capacity Used 100%
Main Input Voltage 230 V
Other Input Voltages 220 V, 240 V
Main Output Voltage 230 V
Other Output Voltages 220 V, 240 V
kW Rating 2100 W
Rated Power (VA) 3000 VA
Input Connection Types BS1363A British, IEC 60320 C20, Schuko CEE 7 / EU1-16P
Output Connection Types 8 × IEC 60320, 2 × IEC Jumpers, 2 × IEC 60320
Number of Rack Units 3U
Cable Length 8 ft (2.4 m)
Number of Cables 1
Provided Equipment CD with software, Relay board, Smart UPS signalling RS-232 cable, User Manual

Battery & Runtime

Feature Specification
Battery Type Lead-Acid battery
Extendable Runtime Yes (1)
Included Battery Modules 2
Typical Recharge Time 2.5 h
RBC Quantity 1
Battery Life 3–5 years
Replacement Battery APCRBC140
Battery Charge Power 359 W rated

General Information

Feature Specification
Number of Power Module Filled Slots 0
Number of Power Module Free Slots 0
Redundant No
Topology Double Conversion Online

Physical Characteristics

Feature Specification
Color Black
Height 17.01 in (43.2 cm)
Width 5.12 in (13 cm)
Depth 25.98 in (66 cm)
Weight 120.26 lb (54.55 kg)
Mounting Location Front
Mounting Preference Lower
Mounting Mode Rack-mounted
Two-Post Mountable No
USB Compatible No

Input Specifications

Feature Specification
Efficiency at Full Load 180–270 V
Input Frequency 50/60 Hz ±5 Hz (auto-sensing)

Output Specifications

Feature Specification
Bypass Type Internal Bypass (Automatic and Manual)
Crest Factor 3:1
Harmonic Distortion Less than 3%
Maximum Configurable Power (VA) 3000 VA
Maximum Configurable Power (W) 2100 W
Waveform Type Sine wave
Output Frequency 50/60 Hz ±3 Hz (user adjustable), ±0.1% (sync to mains)
Additional Output Info Configurable for 220, 230, or 240 V nominal output

Conformance

Certifications CE, DNV, KCC
Standards EN/IEC 62040-1:2019/A11:2021, EN/IEC 62040-2:2006/AC:2006, EN/IEC 62040-2:2018

Environmental Specifications

Feature Specification
Acoustic Level 55 dBA
Online Thermal Dissipation 609 Btu/h
Operating Altitude 0–10,000 ft
Operating Temperature 32–131 °F (0–55 °C)
Storage Temperature 5–113 °F (-15–45 °C)
Storage Altitude 0–50,000 ft (0–15,240 m)
IP Protection IP20
Relative Humidity (Operating & Storage) 0–95% non-condensing
