UPS , Power Back up and accessories
APC Smart-UPS X, Line Interactive,3kVA,Rack/tower convertible 4U,208V,2x L6-20R NEMA+4x C13 IEC+2x C19 IEC, SmartSlot,Extended runtime,Short depth,TAA
- 3kVA/2700W line interactive pure sine wave 4U rack/tower UPS (rail kit AP9625 sold separately)
- User-selectable high voltage setting of 200V-240V
- Add up to 10 external battery packs (SMX120BP)
- Short depth UPS provides extra space for cable management
- Graceful shutdown using serial or USB cables via PowerChute Serial Shutdown
AED17,799.00
This APC Smart-UPS is designed for IT managers or network administrators to maintain business uptime, data transfer and continuity during prolonged power outages. The 3kVA line interactive 4U rack/tower UPS provides pure sine wave power to support critical electronics during power disruptions. The SMX comes with NEMA L6-20P input, 2x NEMA L6-20R, 4x IEC 320 C13 and 2x IEC 320 C19 outlets. The UPS has a SmartSlot for optional Network Management Card that enables graceful shutdown of physical servers, virtual machines & HCI Clusters via PowerChute Network Shutdown. This uninterrupted power supply can connect to EcoStruxure IT or third-party centralized management platforms.
Overview
| Parameter | Details |
|---|---|
| Lead Time | Usually in Stock |
Main Specifications
| Parameter | Details |
|---|---|
| Product Type | Uninterruptible Power Supply (UPS) |
Complementary
| Parameter | Details |
|---|---|
| Communication Port Type | SmartSlot |
Batteries & Runtime
| Parameter | Details |
|---|---|
| Runtime Graph | View Runtime Graph |
| Efficiency Graph | View Efficiency Graph |
| Battery Type | Lead-Acid battery |
| Extendable Run Time | Yes (1) |
| Included Battery Modules | 0 |
| Battery Slots Empty | 0 |
| Typical Recharge Time | 3 h |
| RBC Quantity | 1 |
| Battery Life | 3–5 years |
| Replacement Battery | APCRBC143US |
| Battery Charge Power | 245 W (rated) |
General
| Parameter | Details |
|---|---|
| Provided Equipment | CD with software, Documentation CD, Smart-UPS signalling RS-232 cable, USB cable, User Manual, Rack Mounting Brackets |
| Number of Power Modules | 0 |
| Power Module Slots (Filled/Free) | 0 / 0 |
| Product Web Sub-Family | TAA Compliance |
| Redundant | No |
Physical
| Parameter | Details |
|---|---|
| Rack Units | 4U |
| Number of Cables | 1 |
| Color | Black |
| Height | 17.01 in (43.2 cm) |
| Width | 7.01 in (17.8 cm) |
| Depth | 19.02 in (48.3 cm) |
| Net Weight | 85.19 lb (38.64 kg) |
| Mounting Location | Front |
| Mounting Preference | Lower |
| Mounting Mode | Rack-mounted |
| Two Post Mountable | Yes |
| USB Compatible | Yes |
Input
| Parameter | Details |
|---|---|
| Main Input Voltage | 208 V |
| Other Input Voltage | 220 V, 230 V, 240 V |
| Input Connection Type | NEMA L6-20P |
| Efficiency at Full Load | 141–255 V, 160–280 V |
| Input Frequency | 50/60 Hz ± 3 Hz (auto-sensing) |
Output
| Parameter | Details |
|---|---|
| Main Output Voltage | 208 V |
| Other Output Voltage | 220 V, 230 V, 240 V |
| kW Rating | 2700 W |
| Rated Power (VA) | 3000 VA |
| Output Connection Types | 2× NEMA L6-20R 4× IEC 320 C13 3× IEC Jumpers 2× IEC 320 C19 |
| Crest Factor | 3:1 |
| Harmonic Distortion | Less than 5% |
| Maximum Configurable Power (VA/Watts) | 3000 VA / 2700 W |
| Transfer Time | 2–4 ms (4 ms typical, 8 ms max) |
| Topology | Line Interactive |
| Wave Type | Sine wave |
| Output Frequency (sync to mains) | 50/60 Hz ± 3 Hz |
Conformance
| Certifications |
|---|
| C-tick |
| CE |
| CSA |
| GOST |
| IRAM |
| TAA Compliance |
| VDE |
Environmental
| Parameter | Details |
|---|---|
| Acoustic Level | 55 dBA |
| Online Thermal Dissipation | 184 Btu/h |
| Operating Altitude | 0–10,000 ft |
| Operating Temperature | 32–104 °F (0–40 °C) |
| Storage Temperature | 5–113 °F (-15–45 °C) |
| Storage Altitude | 0–50,000 ft (0–15,240 m) |
| Operating Relative Humidity | 0–95% |
| Storage Relative Humidity | 0–95% |
