Expandable DVI-D Video Matrix up to 32×32

The MXCore-DX Series of DVI-D Matrix Routers allows you to distribute and route any DVI-D input source onto multiple DVI-D display devices. The MXCore-DX Series supports high resolutions up to 1080p, 2K and 1920×1200 with no loss of picture clarity and no ghosting of images. The DVI-D cable is automatically equalized and can compensate the long distance by reducing the number of additional input signals. The Matrix supports DVI-D operation at the maximum TDMS rate of 2×1.65 Gb/s.

SmartAVI MXC-DX32X32S Features:

  • Multiple EDID Support
  • Programmable EDID from computer
  • Automatic EDID learning from monitor
  • Increases productivity by providing access to up to 32 computers from 32 workstations.
  • 32 x 32 non-blocking, single-link DVI-D matrix switch
  • Automatic output pre-emphasis and drive level
  • Automatic receiver equalization
  • Supports DVI-D operation at the maximum rate of 2×1.65 Gbps
  • Supports resolutions up to 1080p, 2K and1920x1200
  • Control from either front panel or RS-232
  • Available IR remote
  • USB Control Available
  • Ethernet control available
  • Easy-to-use Windows based software

SmartAVI MXC-DX32X32S Applications:

  • Wall Displays
  • Digital Signage
  • Airports
  • Dealer Rooms
  • Control Rooms
  • Audio/Visual Presentations
  • Shopping Centers
  • Security
  • Point-of-Sale
  • Hotels/Resorts
  • KVM Switch

SmartAVI MXC-DX32X32S Application Diagram

SmartAVI MXC-DX32X32S Application Diagram

Ā SmartAVI MXC-DX32X32S Specifications:

Mechanical Ā
Width 17.125 in.
Height 12 in.
Depth 12 in.
Video Ā
Video Amplifier Bandwidth 3.2G
Input Video Signal: Video (TMDS) 0.5~1.0VppĀ
DDC Signal: 5 volts
Signal Supports DVI-D Standard, DVI-D and HDCP compliant
Pixel Rates Clock frequency beyond 165Mpix/second
Format 4:4:4 and 4:2:2 data input formats
Resolution Up to 1080p, 2K and 1920 x 1200
Cards Input: 4x DVI FemaleĀ
Output: 4x DVI Female
Slots Input: 8 cards of 4 DVI-D input each Output: 8 cards of 4 DVI-D input each
Video Type RGB/YCBCR : 24/30/36-bits,YCBCR: 8/10/12/16/20/24-bits
Power 50/60Hz, 100~230 VAC
Controls Ā
Working Temperature 0-55 °C
Storage Humidity 10%~90%



SKU: MXC-DX32X32S Categories: , Tags: , ,
Weight 2.3 kg
